Discover the Panik Hydraulic Security Barrier with K12 shock resistance and 2-4 seconds lifting speed. Robust metal design, IP68 waterproof, ideal for ultimate protection.
A control panel must be installed in the bollard to control the barrier.
- Size: 219 600 6 mm
- Box size: 380*1100mm
- Power: 350W
- Plate size: 38cm, thickness: 8mm, material: polished metal
- Column height: 110cm
- Warning sign: High brightness reflective film, with colorful lights
- Column material: SUS304 stainless steel, thickness: 6±0.2mm, body diameter: 219mm
- Outer shell thickness: 2.5mm, black coating
- Lifting height: up to 600 mm
- Buried depth: 1135mm, Buried shell exterior coating: Automotive paint
- Cylinder weight: 90kg (without packaging)
- Driving mode: built-in motor
- Input voltage: AC220V
- Water resistance rating: IP68
- Engine Brand: Panik
- Number of guide rods: 3 (Φ16 chrome plated rod)
- Control mode: control box/remote control
- Emergency function: EPS emergency power supply and one drop button
- Lifting speed: 2-4 seconds
- Ambient temperature: -30~70°C (It is recommended to activate the automatic heating function when the temperature drops below -20°C)
- Storage environment: -10~65℃, rainproof, moistureproof, dustproof, for outdoor use
- Power Outage Emergency: Backup Battery
- Corrosion resistance grade: 9
- Power source: 220V
- Impact resistance rating: K12 (equivalent to a shock at 120 km/h, the vehicle stops, the device operates as normal)
- Pressure bearing: It can bear 100 tons container truck
